Lead Standard 12 Leads
12 channel format recording
Fast ECG test under the [Physical Examination], saving power and paper
7''800×480 graphic 5-inch color screen with Alphabet keyboard input
Built in rechargeable Li-ion battery.
12 lead waveforms view with 250 patient information storage (Extendable)
Built-in USB, RS232 interface, EXGNET software optional
USB interface for net transmission, USB flash disk and USB printer.
High accuracy thermal printing, adapt to 215mm roll paper and 210×140mm Z-fold paper
Work mode MAN, AUTO, ANALYSIS Modes
CMMR ≥100dB (with AC FILTER)
Input Impedance ≥50MΩ
Input circuit current ≤0.05μA
Patient current leakage ＜10μA
Voltage tolerance ≥±500mV
Frequency response 0.05～160Hz(-3db)
Noise level ＜15μVp-p
Communication RSRS232/ USB port
Dimension/Weight 330mm×270mm×72mm/3.8Kg
Power Supply ACAC 110-230V(± ±10%),50/60Hz （ ±1Hz),60VA DC Built-in rechargeable battery,14.4V(2000mmAh)
