(325B)
Main Body High-strength engineering plastic rack, light, beautiful and corrosion resistant
Scope of Application Adult, child
Gas Source O2: 0.27--0.55Mpa; N2O: 0.27--0.55MPa
Flow Rate of Rapid Oxygen Supply 25--75L/min
Low Oxygen Pressure Alarm There will be sound alarm when the oxygen pressure < 0.2MPa
Vaporizer It has the function of automatic compensation based on pressure, temperature, and flow rate. The regulation range of evaporator concentration is 0-5vol%
Among Halothane, Enflurane, Isoflurane and Sevoflurane, one can be chosen for application as required by the customer. And vaporizers that are imported with original packaging are also available
Respiratory Circuit Working mode: all-close, semi-close, semi-open; APL: 0.5-7kPa
Respiratory Bellows Bellows for adults, tidal volume range:0--1500ml; Bellows for children, tidal volume range:0-300ml
Display Mode 10.4” Touch Screen, High-definition TFT color LCD
Ventilation Mode IPPV, SIPPV, SIMV, PEEP, MANUAL, SIGH, IMV, VCV, PCV
Power AC 220V±10%, 50Hz±1Hz, Storage battery (UPS)
Mechanical Arms (End-expiratory CO2 monitoring)
Note: Items within brackets are optional
